BY-Z2172U-N Remote Capable Steel Battery Unit 72W

Model Number BY-Z2172U-N
SKU AA-BY-Z2172U-N Category Tags ,

Please log in or register an account with us to view pricing.

Power your emergency lighting with the AALED Remote Capable Steel Battery Unit, a robust and reliable solution for commercial and industrial applications, operating on AC120-347V at 72W for 30 minutes. It features 2x2W lamps at 2×130 lumens, powered by 12V 7Ah lead acid batteries, and performs reliably in temperatures from 10 to 40°C. Designed to support remote lamp heads, this unit features a durable steel housing, long-lasting battery backup, and energy-efficient operation. Ideal for ensuring safety during power outages, it offers easy installation, maintenance-free performance, and compliance with emergency lighting standards.



UL listed lighting products  Dual Voltage

BY-Z2172U-N Remote Capable Steel Battery Unit 72W

  • Input Voltage: AC120V/277V/347V
  • Remote Capable: 72W – 30mins
  • CCT: 6000K
  • Power Factor > 0.5
  • LED QTY: 6PCs
  • Frequency: 50HZ/60Hz
  • Operation Temperature: 10°C – 40°C
  • Charging Time: 24 Hours
  • Emergency Duration: 120 mins
  • Lamp Power: 2x2W; 2x130LM
  • Battery: Lead Acid Battery 12V 7.0Ah
  • Dimension (mm): 355*338*88MM
  • Cover/Housing Materials: PMMA/ABS+Iron
  • Mounting Type: Wall/End Mounting
  • cULus Listed
  • 10 Year Warranty

Specification Sheets

Specification Sheet

Installation Guides

Installation Guide

IES Files

IES File

Related Products

Model # BY-F5024CA
