Upgrade your fluorescent troffer fixtures to sleek, modern lighting with the AALED Flat Panel, designed for superior energy efficiency and stylish illumination. Perfect for offices, schools, hospitals, retail spaces, and residential settings, this ultra-slim LED panel delivers bright, uniform lighting with excellent color rendering. Featuring an ultra-thin, seamless aluminum frame, long-lasting durability, and easy installation in standard grid ceilings, the AALED Flat Panel reduces energy costs while enhancing any space. Wattage selectable and available in 2×2, 2×4, and 1×4 sizes and 3 color temperatures, it’s the ideal choice for a clean, contemporary lighting solution.
Product replaces and is an alternative to the following:
SKUs: 500812, 500812-BL, 500812H, 500812H-BL, 500812UCCTW, 500812UCCTW2, 500812UCCTW3, 500812UCCTW3-DC12V, 500812UCCTW4-RC-LB, 500813, 500813-BL, 500813D, 500813H-BL, 500813HD, 500829, 500829-35K, 500829H-BL
Model Numbers: KK-PS-22DW-40-LARZ, PL2X230WUNV40K, KK-PS-22DW-40-LARZ, PL2X230W34740K, PL2X2UCCTW, PL2X2UCCTW2, PL-22-BL-347V-40D-SPCDN, PL2X2UCCTW3, PL2X2UCCTW4, KK-PS-22EW-40-LUSA, PL2X230WUNV50K, KK-PS-22EW-40-LARZ, PL2X230W34750K, KK-PS-22EW-40-LARZ, KK-PS-22WW-40-LARZ, KK-PS-22WW-40-LLCZ, PL2X230W34735K
| Rated Voltage (V) | 120-347V |
| Rated Wattage (W) | 25/30/40W |
| Power Factor | >0.90 |
| Luminous Flux (LM) | 3125/3750/5000LM |
| Color Temperature | 3500/4000/5000K |
| Color Rendering Index ( Ra) | >80 |
| Beam Angle | 120° |
| Lamp Efficacy (LM/W) | 114LM/W |
| Rated Lamp Lifetime (h) | LM70 180,000 hrs, LM80 120,000 hrs |
| Dimming | 0-10V Dimming |
| Dimension (mm) | 2X2′ |
