Emergency LED Driver for Strip, AC120-347V

Model Number YH28-08WL-50

Please log in or register an account with us to view pricing.

This Emergency LED Driver for Strip, AC120-347V, 50/60HZ, 80mA, Input Power 5W, output: 15-50VDC, 160-540mA, Output Power: 8W, Discharging time: 90 minutes.



    5-year warranty for LED Post Top



Emergency LED Driver for Strip, AC120-347V

-Universal Input: AC120-347V
-Input Power: 5W
-Power Factor: 0.6@120V; 0.5@347V
-Output Voltage Range: 15-54V
-Recharge Current: 0-200mA
-Discharging Time: 90 Minutes
-Recharge Time: 24 Hours
-Battery: LiFePO4 6.4V, 3.2Ah, 20.48Wh
-IP20 Protection
-Operation Temperature: 10°C-60°C
-cULus Listed for Dry locations
-Warranty: 5 Years



Emergency LED Driver for Strip, AC120-347V



SKU AA-EmergencyLEDDriver-Strip
Model YH28-08WL-50
Voltage AC120-347V
Battery LiFePO4 6.4V,3.2Ah,20.48Wh
Input Power 5W
Discharging Time 90 Minutes
Power Factor 0.6/0.5
Recharging Time 24 Hours
Size 5.9 x 1.7 x 1.0”



Specification Sheets

Specification Sheet

Installation Guides

Installation Guide

IES Files

IES File
